Introduction
This ST has a 5 door hatchback or Wagon type body with a front located engine driving through the front wheels.
Its engine is a turbocharged petrol, 2 litre, double overhead camshaft 4 cylinder with 4 valves per cylinder. It develops 247 bhp (250 PS/184 kW) of power at 5500 rpm, and maximum torque of 340 Nm (251 lb·ft/34.7 kgm) at 1750-4500 rpm. The engine powers the wheels through a 6 speed manual set of gears. The stated kerb weight is 1362 kg. Maximum speed claimed is 248 km/h or 154 mph, quoted fuel consumption figures are 9.9 / 5.6 / 7.2 l/100km urban / extra-urban / combined, and carbon dioxide emissions are 169 g/km.
This ST has a 5 door hatchback or Wagon type body with a front located engine driving through the front wheels.
Its engine is a turbocharged petrol, 2 litre, double overhead camshaft 4 cylinder with 4 valves per cylinder. It develops 247 bhp (250 PS/184 kW) of power at 5500 rpm, and maximum torque of 340 Nm (251 lb·ft/34.7 kgm) at 1750-4500 rpm. The engine powers the wheels through a 6 speed manual set of gears. The stated kerb weight is 1362 kg. Maximum speed claimed is 248 km/h or 154 mph, quoted fuel consumption figures are 9.9 / 5.6 / 7.2 l/100km urban / extra-urban / combined, and carbon dioxide emissions are 169 g/km.
| 2012 FORD FOCUS ST250 DATA | |
| bodywork | |
| body type | hatchback or wagon |
| number of doors | 5 |
| designer | |
| dimensions & weights | mm |
| wheelbase | 2648 |
| track/tread (front) | 1554 |
| track/tread (rear) | 1544 |
| length | 4362 |
| width | 1823 |
| height | 1484 |
| ground clearance | |
| length:wheelbase ratio | 1.65 |
| kerb weight | 1362 kg |
| weight distribution | |
| fuel tank capacity | 62L |
| aerodynamics | |
| drag coefficient | |
| frontal area | |
| cda | |
| engine | |
| engine type | turbocharged petrol |
| engine manufacturer | Ford |
| engine code | C346ST |
| cylinders | Straight 4 |
| capacity | 2 litre (1999cc) |
| bore x stroke | 87.5 x 83.1 mm |
| bore/stroke ratio | 1.05 |
| camshaft | double overhead camshaft (DOHC) |
| valves per cylinder | 4 |
| valves in total | 16 |
| maximum power output | 250 PS (184 kW) at 5500 rpm |
| specific output | 123.6 bhp/litre |
| maximum torque | 340 Nm (34.7 kgm) at 1750-4500 rpm |
| specific torque | 170.09 Nm/litre |
| engine construction | |
| sump | wet sumped |
| compression ratio | 9.3:1 |
| fuel system | ERFS direct petrol injection |
| bmep (brake mean effective pressure) | 2137.4 kPa (310 psi) |
| maximum rpm | |
| engine coolant | Water |
| unitary capacity | 499.75 cc |
| aspiration | Turbo |
| compressor | |
| intercooler | Y |
| catalytic converter | Y |
| performance | |
| acceleration 0-80km/h | |
| acceleration 0-100km/h | 6.50 s |
| acceleration 0-160km/h | |
| standing kilometre | |
| maximum speed | 248 km/h (154 mph) |
| power-to-weight ratio | 183.87 PS/ton (135.23 kW/ton) |
| weight-to-power ratio | 7.39 kg/kW |
| fuel consumption | |
| fuel consumption L/100km | 9.9 / 5.6 / 7.2 urban / extra-urban / combined |
| fuel consumption km/L | 10.1 / 17.9 / 13.9 urban / extra-urban / combined |
| carbon dioxide emissions | 169 g/km |
| carfolio calculated CO2 | 167.04 g/km |
| ved band (uk) | H |
| co2 effizienz (de) | E |
| chassis | |
| engine position | front |
| engine layout | transverse |
| drive wheels | front wheel drive |
| torque split | N/A |
| steering | rack & pinion PAS |
| turns lock-to-lock | 1.8 |
| turning circle | |
| front suspension | I.MS.CS.ARB. |
| rear suspension | I.CS.ARB. |
| wheel size front | 8½ x 18 |
| wheel size rear | 8½ x 18 |
| tyres front | Goodyear Eagle AS2 235/40 R 18 |
| tyres rear | Goodyear Eagle AS2 235/40 R 18 |
| brakes f/r | VeDi/Di-S-ABS |
| front brake diameter | 320 mm |
| rear brake diameter | 271 mm |
| gearbox | 6 speed manual |
| top gear ratio | 0.94 |
| final drive ratio | 4.06 |
| general | |
| carfolio.com id | 256157 |
| production total |
